Cnc Hlau Bender
Dabtsi ua haujlwm thiab kev siv tshuab (patented technology): khoov tus cwj pwm tsav los ntawm servo lub cav yuav rub tawm lossis kos rov qab thaum uas siv ntau lub kaum sab xis, thaum txiav qhov tau txais lub teeb liab, nws yuav ua tiav cov hauj lwm synchronously. Tswj lub cev: CNC tswj nrog malfunction tswb, PLC, servo tsav ...
- Khoom Taw qhia
Dabtsi yog khoov thiab lub kaw lus ( patented technology ):
bending caj npab tsav los ntawm servo lub cev muaj peev xwm tiv thaiv los yog kos rov qab thaum uas khoov cov ces kaum sib txawv, thaum txiav qhov tau txais lub teeb liab, nws yuav ua tiav kev ua hauj lwm synchronously.
Tswj lub kaw lus :
CNC tswj nrog lub tswb nrov, PLC , servo lub cev thiab cov khoom siv hluav taws xob siv Nyiv thiab lub tebchaws Yelemees hom .
Khoom noj khoom haus:
2 payoffs nrog brakes, haum rau ib zaug thiab ob leeg strand, buffer unit yuav txo qhov tsis kam thiab instability thaum txoj kev decoiling.
CNC STEEL BAR STIRRUP BENDER SGW12D-1 | ||
TENSILE STRENGTH | Kg / hli 2 45 | Kg / hli 2 65 |
IB TUG HLAU DABTSI YOG KHOOV | 6-12 hli | 5-11 hli |
OB CHAV HLOOV DABTSI YOG KHOOV | 6-10 hli | 5-8 hli |
KEV QHIA | Tsis siv neeg hlau noj lawv (CNC) | |
MAX. BENDING LUB HLWB | 180 ° | |
MAX. LENGTH NTAWM STIRRUP SIDE | 900 hli | |
MIN. LENGTH NTAWM STIRRUP SIDE | 90 hli | |
MAX. BENDING ceev | 1050 ° / sec | |
MAX. TRACTION SPEED | 75-100 m / min | |
TRACTION SERVICE QOJ zog | 13KW | |
BENDING SERVICE QOJ zog | 7KW | |
